| Mechanical |
| Dimensions | 442 x 120 x 43.7 mm (17.4 x 4.7 x 1.7") |
| Weight | Without mounting brackets: 2.6 kg (5.8 lb)
With mounting brackets: 2.7 kg (6 lb) |
| Enclosure material | SGCC steel |
| Hardware |
| Management interface | Ethernet In-Band |
| Networking interface | (8) 10G SFP+ ports |
| Total non-blocking throughput | 80 Gbps |
| Switching capacity | 160 Gbps |
| Forwarding rate | 119.04 Mpps |
| Power method | Universal input, 100—240V AC, 50/60 Hz |
| Power supply | AC/DC, internal, 36W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 30W |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Max. number of supported SFP+ modules | UACC-OM-MM-10G: 8
UACC-OM-SM-10G: 8
UACC-CM-RJ45-10G: 4
UACC-CM-RJ45-MG: 4 |
| Services | SMB Layer 2 GbE switch |
| LCM display | (1) 1.3" LCM color touchscreen |
| Button | Factory reset |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features |
| Layer 2 features | IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs |
| Layer 3 features | – |
| LEDs |
| System | Status |
| SFP+ | Link/activity |
