| Model | RG-EST310 |
| Hardware Specifications |
| RAM/ Flash | 64MB/8MB |
| Radio | Dual-stream single-band 2×2 |
| Operating Band | 802.11a/n/ac:5.725~5.850GHz |
| Antenna | Built-in directional antennas, horizontal: 60°, vertical: 30°, gain: 10dBi |
| Spatial Streams | 2 |
| Maximum Throughput | Up to 867Mbps at 5GHz |
| Transmit Power | ≤250mW |
| Dimensions | 147mm(D)×76mm(W)×37mm(H) (Dimensions per device) |
| (Same size for the transmitter and receiver, |
| H: height of the device excluding the mounting kits) |
| Weight | 0.35kg |
| Ports | 1 10/100Base-T Ethernet port, supports 24VDC non-standard PoE |
| 1 DC port, supports 12VDC power supply |
| Hardware Button | 1 reset button |
| Status Indicators | System indicator: 1 |
| Port indicator: 1 |
| Bridge signal strength indicators: 3 |
| Power Supply | Support 12VDC power supply and 24VDC non-standard PoE |
| Power Consumption | <5W |
| Environment | Operating temperature: -30°C~50°C |
| Storage temperature: -40°C~70°C |
| Operating humidity: 5% to 95% (non-condensing) |
| Storage humidity: 5% to 95% (non-condensing) |
| Installation | Wall-mounted/ Pole-mounted (straps provided) |
| IP Rating | IP65 |
| Lightning Protection | 4KV |
| Radio Standard | SRRC certification |
| Automatic Bridging | The recorder-end and camera-end are automatically paired for bridging by default |
Device Configuration and
Management | Support App/Web configuration |
| QR Code Login | Users can log in to the device configuration interface by scanning the QR code
of the device using the app |
| Self-healing | Automatic restart upon equipment failure |
| Automatic Channel Adjustment | Automatically adjust the channel upon power-on |
