| Adaptör | ADAPTÖRSÜZ | ADAPTÖRSÜZ |
| Hardware specifications |
| Radio | Dual-stream dual-band |
| Protocol | Concurrent 802.11ac wave2, wave1, 802.11a/b/g/n |
| Operating Bands | 802.11b/g/n :2.4G ~ 2.4835GHz 802.11a/n/ac : 5G:5.150~5.250GHz,5.725~5.850GHz (country specific) |
| Antenna | Internal antennas(2.4G: 2dBi,5G: 2dBi) |
| Spatial Streams | 2.4G 2x2MIMO 5G 2x2MIMO |
| Max Throughput | Up to 400Mbps at 2.4G Up to 867Mbps at 5G 1.267Gbp per AP |
| Modulation | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM |
| Receive Sensitivity | 11b: -91dBm (1Mbps), -88dBm (5Mbps), -85dBm (11Mbps) 11a/g: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps) 11n: -83dBm@MCS0, -65dBm@MCS7, -83dBm@MCS8, -65dBm@MCS15 11ac HT20: -83dBm (MCS0), -57dBm (MCS9) 11ac HT40: -79dBm (MCS0), -57dBm (MCS9) 11ac HT80: -76dBm (MCS0), -51dBm (MCS9) |
| Maximum Transmit Power | 5.725~5.850GHz:≤20dBm (EIRP) 5.150~5.250GHz:≤20dBm (EIRP) 2.4~2.4835GHz:≤20dBm (EIRP) |
| Adjustable Power | 1dBm | 1dBm |
| Dimensions | 194mm×194mm×35mm (excluding mounting kits) | 194mm×194mm×35mm (excluding mounting kits) |
| Weight | 0.45kg (excluding mounting kits) | 0.45kg (excluding mounting kits) |
| Service Ports | 2 10/100/1000Base-T Ethernet ports, PoE/LAN1 port supports PoE | 2 10/100Base-T Ethernet ports, PoE/LAN1 port supports PoE |
| Management Port | NA | NA |
| LED Indicator | NA | NA |
| Power Supply | Single indicator (green light) |
| Power Consumption | Local power supply, DC 12V/1.5A (Note: The power adapter is sold as an optional accessory) 802.3af/802.3at PoE |
| Environment | ≤ 12.95W |
| Operating temperature: 0°C~40°C |
| Storage temperature: -40°C~70°C |
| Operating humidity: 5%~95%(non-condensing) |
| Installation | Storage humidity: 5%~95%(non-condensing) |
| Safety Standard | GB4943, IEC 62368-1 |
| EMC Standard | GB9254,EN301 489,EN50155,EN50121,EN55032,EN61000,EN55035 |
| Vibration Standard | IEC61373 |
| Radio Standard | EN300 328, EN301 893 |
| MTBF | >250000H | >250000H |
| Software Features | |
| Operating Mode | AP mode and routing mode |
| WLAN | Maximum number of clients: 110 |
| Recommended number of clients: 80 (16 at 2.4GHz, 64 at 5GHz) | Recommended number of clients: 48 (16 at 2.4GHz, 32 at 5GHz) |
| Up to 8 SSIDs |
| Support SSID hiding Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID |
| SSID-based and radio-based STA limit |
| Support Layer 2 user isolation |
| Roaming | Support Layer 2 and Layer 3 roaming |
| Security | Support PSK authentication |
| Support static blacklist and whitelist |
| Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption |
| Routing | Support static IP address, DHCP, PPPoE Dial Up |
| Management and maintenance | Support unified networking of all network equipment Support local or remote management with Ruijie Cloud app Support local management with web Support remote management with Ruijie Cloud platform |
| Platform management features | Automatic RF adjustment via the platform |
| Unified configuration via the platform |
| Unified monitoring via the platform |
