Wireless |
Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Signal Rate | Up to 300Mbps |
Frequency Range | 2.4-2.4835GHz |
Transmit Power | 20dBm(MAX) |
Data Transfer Rate | 802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps) 20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense) 801.11g:(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps) 802.11b:(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps) |
Wireless Mode | AP, WDS, AP+WDS, Repeater, Client, Multi-SSID |
Wireless Security | 64/128-bit WEP, |
WPA-PSK/WPA2-PSK (TKIP/AES) |
SSID Broadcast Enable/Disable |
Wireless MAC Filtering |
Hardware |
Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX |
Interface | 1 * 10/100Mbps Auto MDI/MDIX RJ45 WAN port |
4 * 10/100M Auto MDI/MDIX RJ45 LAN port |
LED | PWR, WLAN, LAN1-LAN4, WAN, WPS |
Button | WPS/ Default |
Antenna | 3* 5dBi Fixed Antenna |
Power Supply | DC 9V/500mA (Output) |
Software |
WAN Type | DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access, WISP |
Port Forwarding | Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port |
QoS | WMM, Bandwidth Control |
Access Control | IP/MAC/Domain filtering |
VPN Pass-through | PPTP, L2TP, IPSec |
Others | IPTV, Dynamic DNS, Static Routing, WOL, Backup & Restore, Firmware Upgrade |
Others |
Certification | FCC, CE |
Environment | Operating Temperature: 0?~40? |
Storage Temperature: -40?~70? |
Operating Humidity: 10%~90% non-condensing |
Storage Humidity: 5%~90% non-condensing |
Package | 1* WF2409E |
1* 9V/500mA Power Adapter |
1* Quick Installation Guide (Multilingual) |
