Wireless |
Standards | IEEE 802.11b/g/n 2.4GHz |
IEEE 802.11a/n/ac 5GHz |
Signal Rate | Up to 300Mbps2.4GHz |
UP to 867Mbps 5GHz |
Frequency Range | 2.4-2.4835GHz;5.180-5.825GHZ |
Transmit Power | 20dBm(MAX) |
Data Transfer Rate | 802.11ac:80MHZ(433Mbps, 867Mbps) |
802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps) 20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps,43Mbps, 28Mbps, 14Mbps) (Auto-Sense) |
801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps) |
802.11b: (11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps) |
Wireless Modes | AP, Repeater, Client, Multi-SSID |
Wireless Security | WEP/WPA-PSK/WPA2-PSK Encryption |
Wireless MAC Filtering |
Hardware |
Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T |
Interface | 1*10/100/1000Mbps Auto MDI/MDIX RJ45 WAN port |
4*10/100/1000Mbps Auto MDI/MDIX RJ45 LAN port |
LED Indicators | SYS, WPS, 5G, 2.4G, WAN, LAN1~LAN4 |
Buttons | Default, WPS |
Antenna | 4* external fixed 5dBi antenna |
Power Supply | DC 12V/1.0A(Output) |
Dimensions L x W x H ) | 212 x 145 x 40 mm |
WAN Type | DHCP, Static IP, PPPoE, L2TP, PPTP, WISP |
Others | Bandwidth Control, Access Control, IPTV, Virtual Server, DMZ, |
VPN Pass-through, Dynamic DNS, Static Routing, Backup &Restore |
Others |
Certification | FCC, CE, EAC |
Environment | Operating Temperature: 0?~40? |
Storage Temperature: -40?~70? |
Operating Humidity: 10%~90% non-condensing |
Storage Humidity: 5%~90% non-condensing |
Package | 1* N2 |
1* 12V/1.0A Power Adapter |
1* Ethernet Cable |
1* Quick Installation Guide (Multilingual) |
