| Specification |
| Wireless |
| Standards | Wi-Fi 5 |
| IEEE 802.11ac/n 5 GHz |
| IEEE 802.11b/g/n 2.4 GHz |
| WiFi Speeds | AC1200 |
| 5 GHz: 867Mbps (802.11ac) |
| 2.4 GHz: 300Mbps (802.11n) |
| WiFi Range | 3 Bedroom Houses |
| 4x Fixed High-Performance Antennas |
| Multiple antennas form a signal-boosting array to cover more directions and large areas |
| Beamforming Concentrates wireless signal strength towards |
| clients to expand WiFi range |
| High-Power FEM Improves transmission power to strengthen signal coverage |
| WiFi Capacity | Dual-Band |
| Allocate devices to different bands for optimal performance |
| OFDMA |
| Simultaneously communicates with multiple Wi-Fi 5/4 clients |
| Airtime Fairness |
| Improves network efficiency by limiting excessive occupation |
| 4 Streams Connect your devices to more bandwidth |
| Working Modes | AP Router Mode, AP Mode, WISP Mode, Client Mode, Repeater Mode |
| Hardware |
| Processor | 1GHz CPU |
| Main Chipset | RTL8197FH-VG5+RTL8812FR |
| DDR/FLASH | 128MB/8MB |
| Interface | 1x Fast WAN Port+3x Fast LAN Ports |
| Buttons | WPS?RESET |
| Power | 12V1A |
| Software |
| WiFi Encryption | WEP, WPA-PSK, WPA2-PSK, WPA/WPA2-PSK |
| Network Security | Access Control, IP & MAC Binding |
| Guest Network | 4*5GHz Guest Network /4*2.4GHz Guest Network |
| Protocols | IPv4, IPv6 |
| WAN Types | DHCP, Static IP, PPPoE, L2TP, PPTP |
| Quality of Service | QoS by Device |
| NAT Forwarding | Virtual Server, DMZ, UPnP |
| IPTV | Bridge, Tag VLAN |
| DHCP | Address Reservation, DHCP Client List, DHC Server |
| Access Control | IP Filtering, MAC Filtering, Domain Filtering, IPv6 Filtering |
| DDNS | DynDns, NO-IP |
| IGMP | IGMP IGMP Proxy, IGMP Snooping |
| VPN | PPTP Pass-through, L2TP Pass-through, IPSEC Pass-through, SIP Pass-through |
| Others | Others Bandwidth Control, Multiple SSID, FOTA, TR069, WOL, ARP List, Static Routing, Port Setting, Remote Access, Backup & Restore |
| Physical |
| Dimensions(W×D×H) | 228*134*188mm |
| Package Contents | 1* NC21 |
| 1* Power Adapter |
| 1* RJ45 Ethernet Cable |
| 1* Quick Installation Guide |
| Others |
| System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
| Cable Subscription with an internet service provider (for internet access) |
| Certifications | FCC, CE, RoHS , EAC, UkrSEPRO |
| Environment | Operating Temperature: 0?~40? ( 32? ~104? ) |
| Storage Temperature: -40?~70? (-40? ~158? ) |
| Operating Humidity: 10%~90% non-condensing |
| Storage Humidity: 5%~90% non-condensing |
| Test Data |
| WiFi Transmission Power | 2.4H: 22DB |
| 5G: 19.5DB |
