  |   Hardware specifications   |
  |   Radio   |    Dual-stream dual-band   |
  |   Protocol   |    Concurrent 802.11ac wave2, wave1, 802.11a/b/g/n   |
  |   Operating Bands   |    802.11b/g/n :2.4G ~ 2.4835GHz  802.11a/n/ac : 5G:5.150~5.250GHz,5.725~5.850GHz (country specific)   |
  |   Antenna   |    Internal antennas(2.4G: 2dBi,5G: 2dBi)   |
  |   Spatial Streams   |    2.4G 2x2MIMO 5G 2x2MIMO   |
  |   Max Throughput   |    Up to 400Mbps at 2.4G  Up to 867Mbps at 5G  1.267Gbp per AP   |
  |   Modulation   |    OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps  DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps  MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM   |
  |   Receive Sensitivity   |    11b: -91dBm (1Mbps), -88dBm (5Mbps), -85dBm (11Mbps)  11a/g: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps)  11n: -83dBm@MCS0, -65dBm@MCS7, -83dBm@MCS8, -65dBm@MCS15  11ac HT20: -83dBm (MCS0), -57dBm (MCS9)  11ac HT40: -79dBm (MCS0), -57dBm (MCS9)  11ac HT80: -76dBm (MCS0), -51dBm (MCS9)   |
  |   Maximum Transmit Power   |    5.725~5.850GHz:≤20dBm (EIRP)  5.150~5.250GHz:≤20dBm (EIRP)  2.4~2.4835GHz:≤20dBm (EIRP)   |
  |   Adjustable Power   |    1dBm   |    1dBm   |
  |   Dimensions   |    194mm×194mm×35mm (excluding mounting kits)   |    194mm×194mm×35mm (excluding mounting kits)   |
  |   Weight   |    0.45kg (excluding mounting kits)   |    0.45kg (excluding mounting kits)   |
  |   Service Ports   |    2 10/100/1000Base-T Ethernet ports, PoE/LAN1 port supports PoE   |    2 10/100Base-T Ethernet ports,  PoE/LAN1 port supports PoE   |
  |   Management Port   |    NA   |    NA   |
  |   LED Indicator   |    NA   |    NA   |
  |   Power Supply   |    Single indicator (green light)   |
  |   Power Consumption   |    Local power supply, DC 12V/1.5A (Note: The power adapter is sold as an optional accessory)  802.3af/802.3at PoE   |
  |   Environment   |    ≤ 12.95W   |
  |   Operating temperature: 0°C~40°C   |
  |   Storage temperature: -40°C~70°C   |
  |   Operating humidity: 5%~95%(non-condensing)   |
  |   Installation   |    Storage humidity: 5%~95%(non-condensing)   |
  |   Safety Standard   |    GB4943, IEC 62368-1   |
  |   EMC Standard   |    GB9254,EN301 489,EN50155,EN50121,EN55032,EN61000,EN55035   |
  |   Vibration Standard   |    IEC61373   |
  |   Radio Standard   |    EN300 328, EN301 893   |
  |   MTBF   |    >250000H   |    >250000H   |
  |   Software Features   |        |
  |   Operating Mode   |    AP mode and routing mode   |
  |   WLAN   |    Maximum number of clients: 110   |
  |   Recommended number of clients: 80 (16 at 2.4GHz, 64 at 5GHz)   |    Recommended number of clients: 48 (16 at 2.4GHz, 32 at 5GHz)   |
  |   Up to 8 SSIDs   |
  |   Support SSID hiding  Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID   |
  |   SSID-based and radio-based STA limit   |
  |   Support Layer 2 user isolation   |
  |   Roaming   |    Support Layer 2 and Layer 3 roaming   |
  |   Security   |    Support PSK authentication   |
  |   Support static blacklist and whitelist   |
  |   Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption   |
  |   Routing   |    Support static IP address, DHCP, PPPoE Dial Up   |
  |   Management and maintenance   |    Support unified networking of all network equipment  Support local or remote management with Ruijie Cloud app  Support local management with web  Support remote management with Ruijie Cloud platform   |
  |   Platform management features   |    Automatic RF adjustment via the platform   |
  |   Unified configuration via the platform   |
  |   Unified monitoring via the platform   |
