| Mechanical |
  | Dimensions |  200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
  | Weight |  2.4 kg (5.29 lb) |
  | Enclosure material |  Polycarbonate |
  | Mount material |  Polycarbonate |
  | Hardware |
  | Management interface |  Ethernet In-Band |
  | Networking interface |  (8) 2.5 GbE, PoE+ RJ45 ports  (2) 10G SFP+ |
  | PoE interface |  (8) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
  | Total non-blocking throughput |  40 Gbps |
  | Switching capacity |  80 Gbps |
  | Forwarding rate |  59.52 Mpps |
  | Power method |  (1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz |
  | Power supply |  AC/DC, internal, 150W |
  | Supported voltage range |  100—240V AC |
  | Max PoE power |  120W |
  | Max. PoE+ wattage per port by PSE |  32W |
  | Voltage range PoE mode |  PoE: 44—57V  PoE+: 50—57V |
  | LCM Display |  (1) 1.3" color touchscreen |
  | Mounting |  Desktop-mountable (Do not physically stack the USW-Enterprise-8-PoE.) |
  | ESD/EMP protection |  Air: ± 16kV, contact: ± 12kV |
  | Operating temperature |  -5 to 45° C (23 to 113° F) |
  | Operating humidity |  10 to 90% noncondensing |
  | Certifications |  CE, FCC, IC |
  | LEDs |
  | System |  Status |
  | Ethernet |  Link/activity |
  | SFP+ |  Link/activity |
  | Application Requirements |
  | UniFi Network |  Version 6.3.51 and later |
