| Specifications | parameter |
| switching capacity | 128Gbps |
| Packet forwarding rate | 132Mpps |
| MAC table entry | 8K |
| Buffer value | 4M |
| Jitter delay | 9.62ns |
| Size | 440mm × 265mm × 45mm |
| weight | 5kg |
| Power | 450W |
| working temperature | 0~55°C |
| Storage temperature | -10~70°C |
| Working humidity | 10%~90% no condensation |
| Storage humidity | 5%~95% no condensation |
| VLAN | Maximum support for 4096 VLANs |
| Support port-based VLAN |
| VLAN Supporting 802.1Q Standard |
| spanning tree | Support RSTP Fast Spanning Tree Protocol |
| Ring network | Supporting Fast Loop Networks |
| Erps | support |
| Route | Static Route, OSPF |
| Port aggregation | Support static aggregation |
| Port mirroring | Support multi-to-one port mirroring without restriction on the number of mirror source ports |
| Loop Guard | Supporting Loop Detection/Loop Avoidance |
| Port flow control | Supporting half-duplex control based on backpressure |
| line rate | Support port-based input/output bandwidth management |
| IGMP Snooping | Support IGMP Snooping |
| DHCP | Support DHCP Client |
| Storm suppression | Supporting suppression of broadcasting, multicast, unicast, etc |
| Negotiation mode | Support port auto-negotiation (self-negotiation transmission rate and duplex mode) |
| system maintenance | Supporting profile upload/download |
| Support upgrade package upload |
| Support WEB to restore factory configuration |
| Support System Logging Function |
| Network management | Support WEB interface management, CONSOLE,Telnet |
