| Technical Speci?cation |
| Model | DHI-VTO2111D-P-S2 |
| System |
| Main Processor | Embedded processor |
| Operating System | Embedded LINUX operating system |
| Button Type | Mechanical |
| Interoperability | ONVIF |
| Internet Protocol | SIP; P2P; IPv4; DNS; RTSP; RTP; TCP; UDP |
| Baisc |
| Camera | 1/4" 1MP CMOS high definition, low illumination/WDR, color/IR |
| Angle of View | Horizontal: 107°; vertical: 61°; diagonal: 122° |
| WDR | Yes |
| Noise Reduction | 3D noise reduction |
| Video Compression | H.264 |
| Video Resolution | Main stream: WVGA, 720P, D1 Sub stream: CIF, WVGA, QVGA, 1080P, D1 |
| Frame Rate | PAL: 25 fps NTSC: 30 fps |
| Video Bit Rate | 256K to 4M |
| Light Compensation | Auto IR |
| D/N | ICR auto switch |
| Audio Compression | G.711a; PCM; AAC |
| Audio Input | 1 |
| Audio Output | Built-in speaker |
| Audio Mode | Two-way voice call |
| Audio Enhancement | Echo suppression and cancellation/digital noise reduction |
| Audio Bit Rate | 16KHz, 16Bit |
| Function |
| Communication | Full digital |
| Unlock Mode | Card/App remote/indoor monitor unlock |
| Card Type | IC card |
| Motion Detection | Video motion detection |
| Auto Snapshot | Auto snapshot can only be enabled on indoor monitors |
| Leave Photos and Messages | Yes (SD card is needed) |
| Web Configuration | Yes |
| Performance |
| Card Reading Distance | 3cm–5cm |
| Casing | PC+Acrylic |
| Capacity |
| Card | 10,000 |
| Port |
| RS-485 | 1 |
| Electric Lock | 1 |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1, normally closed by default |
| Network | 1 10Mbps/100Mbps network port (8-core white ribbon cable) |
| Alarm |
| Tamper | Yes |
| General |
| Color | Black |
| Power Supply Mode | 12V DC 1A
Standard PoE |
| Installation | Surface mount |
| Certifications | CE
FCC
UL |
| Accessory | Brackets and alarm ribbon cable |
| Dimensions | 135mm×70.4mm×34.4mm (5.31"×2.77"×1.35") |
| Protection Grade | IP65 (silicone sealant is needed, see the quick start guide) |
| Operating Temperature | -30°C to +60°C (-20°F to +60°F ) |
| Operating Humidity | 10%RH–90%RH (non-condensing) |
| Operating Altitude | Beneath 3000 m (9842.52 ft) |
| Power Consumption | Standby≤1W, working≤5W |
| Gross Weight | 326 g (0.72 lb) |
| | |
| Model | DHI-VTH2421FB-P |
| Main Processor | High performace embedded processor |
| Operating System | Embedded LINUX OS |
| Screen Type | Capacitive screen |
| Display | 7-inch TFT screen |
| Resolution | 1024 × 600 |
| Video Compression | H.264 |
| Audio Compression | G.711A/G.711U/PCM |
| Audio Input | 1 channel all-direction microphone |
| Audio Output | Built-in 1.5W loudspeaker |
| Audio Mode | Support dual-way bidirectional talk |
| Audio Enhancement | Support echo cancellation/DNR |
| Audio Bit Rate | 16 kbps |
| Communication Mode | Full digital |
| Information Release | Support to receive and view notifications issued by center |
| Leave Videos or Text Messages | Yes |
| DND Mode | Support to set DND period |
| Sub-station Quantity | 9 |
| Alarm Input | 6 channel (switch quantity) |
| Alarm Output | 1 channel |
| Network | 1 RJ-45 |
| SOS Alarm | Yes |
| Casing | PC+ABS |
| Appearance Color | Appearance Color |
| Power Supply | Power Supply |
| Installation | Wall mount |
| Accessories | Default bracket
Default alarm cable |
| Dimensions | 119.6 mm × 221.5 mm × 21.5 mm (4.71" × 8.72" × 0.85") |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Operating Humidity | 10%RH-95%RH |
| Power Consumption | Standby≤4W, work≤6W |
| Gross Weight | 0.35 Kg (0.77 lb) |
| Power Supply Mode | PoE or DC 12V |
| Storage | Support Micro SD, maximum memory capacity 32 G, standard memory capacity 8 G |
| | |
| Model | DH-PFS3005-4ET-36 |
| Main Processor | High performace embedded processor |
| Ethernet Port | 1×10/100 Base-T 4×10/100 Base-T (PoE power supply) |
| PoE Power Consumption | Each power ≤30W, Total≤36W |
| PoE Protocol | IEEE802.3af, IEEE802.3at |
| Weight | 0.5kg |
| Dimension(W×D×H) | 170mm×100mm×35mm |
