Standard: | AHD, HD-CVI, HD-TVI, CVBS |
Sensor: | 1/2.8 " CMOS |
Matrix size: | 2.16 Mpx |
Resolution: | 1920 x 1080 - 1080p , |
1280 x 720 - 720p , | |
960 x 576 - 960H, PAL | |
Lens: | 3.6 mm |
View angle: | 87 ° (manufacturer data) |
83 ° (our tests result) | |
White light LED illuminator range: | 40 m |
Video output: | AHD / HD-CVI / HD-TVI / CVBS, 1 Vpp / 75 Ω |
Audio: | Microphone built-in |
Audio support via coaxial cable - HD-CVI only | |
OSD menu: | OSD menu available via DAHUA recorder |
Main features: | Possibility to turn off the LED illuminator |
D-WDR - Wide Dynamic Range | |
2D-DNR - Digital Noise Reduction | |
F-DNR (Defog) - Reduction of image noise caused by precipitation | |
BLC/HLC - Back Light / High Light Compensation | |
Sharpness - sharper image outlines | |
AGC - Automatic Gain Control | |
Privacy zones | |
Mirror - Mirror image | |
Auto White Balance | |
"Index of Protection": | IP67 |
Power supply: | 12 V DC / 350 mA |
Power consumption: | ≤ 4.2 W |
Housing: | Dome, Aluminum + Plastic |
Vandal-proof: | - |
Color: | White + Black |
Operation temp: | -40 °C ... 60 °C |
Weight: | 0.3 kg |
