HIKVISION (iDS-7232HQHI-M2/S) 32 KANAL 1xSES 1xHDMI 1xVGA 2xSATA (2x10TB) 1xRJ45 2xIP HD-TVI

Henüz Değerlendirilmemiş

Stok Kodu

: Y5311207

Stok Miktarı

: 2 ADET

Whatsapp ile Sipariş

Acucense özellikli 2 Adet Akıllı analiz yapar ve tüm kanallar seslidir.

32-ch 1080p 1U H.265 AcuSense DVR

Deep learning-based motion detection 2.0 for all analog channels
Deep learning-based perimeter protection
Efficient H.265 pro+ compression technology
Encoding ability up to 1080p @ 15 fps
5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
Up to 40 network cameras can be connected

Motion Detection : 2.0
Human/Vehicle Analysis :
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

Quick search by object or event type is supported;

Perimeter Protection
Human/Vehicle Analysis : Up to 4-ch

Recording
Video Compression : H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution
Main stream:

When 1080p Lite mode not enabled:

For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps

For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

When 1080p Lite mode enabled: 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)
Video Bitrate : 32 Kbps to 10 Mbps
Dual-stream : Support
Stream Type : Video, Video & Audio
Audio Compression : G.711u
Audio Bitrate : 64 Kbps

Video and Audio
IP Video Input : 2-ch (up to 34-ch)
Enhanced IP mode on: 8-ch (up to 40-ch), each up to 4 Mbps,Up to 6 MP resolution,

Support H.265+/H.265/H.264+/H.264 IP cameras
Analog Video Input : 32-chBNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input : 4 MP@30 fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps
*: The 3 MP signal input is only available for channel 1/2/3/4.
AHD Input : 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
HDCVI Input : 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
CVBS Input : PAL/NTSC
CVBS Output :
1-ch, BNC (1.0 Vp-p, 75 Ω),

resolution: PAL: 704 × 576, NTSC: 704 × 480
HDMI Output : 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output :
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

HDMI/VGA simultaneous output
Audio Input : 1-ch, RCA (2.0 Vp-p, 1 KΩ),32-ch via coaxial cable
Audio Output : 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio : 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Synchronous playback : 16-ch

Network
Remote Connection : 128
Network Protocol : TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network Interface :
1,RJ45 10/100/1000 Mbps self-adaptive

Ethernet interface
Wi-Fi : Wi-Fi Connectable to Wi-Fi network by Wi-Fi dongle through USB interface

Auxiliary Interface
SATA : 2 SATA interfaces
Capacity : Up to 10 TB capacity for each disk
Serial Interface : RS-485 (half-duplex)
USB Interface
Front panel: 1 × USB 2.0

Rear panel: 1 × USB 3.0
Alarm In/Out : N/A (optional to support)

General
Power Supply : 12 VDC, 5 A
Consumption : ≤ 40 W
Working Temperature : -10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity : 10% to 90%
Dimension (W × D × H) : 380 × 320 × 48 mm (15.0” × 12.6” × 1.9”)
≤ 2.1 kg (4.6 lb)
