| System | OS | Embedded Linux |
| OS Operation Interface | Web/operating in local GUI |
| AI by Camera | Perimeter Protection | 16 channels |
| Face Detection | 16 channels |
| SMD | 16 channels |
| Video&Audio Input | Incoming bandwidth | 128Mbps |
| Output bandwidth | 128Mbps |
| IPC Input | 16CH |
| Video&Audio Output | VGA | 1920×1080,1280×1024,1280×720,1024×768 |
| HDMI | 3840×2160,1920×1080,1280×1024,1280×720,1024×768 |
| Audio Output | 1CH,RCA(Line out,2Vp-p,300ohms) |
| Audio Encoding | Audio Compression | G.711A |
| Audio Bit Rate | 8Kbps(16bit) |
| Video&Audio Decoding | IP channel Resolution | Up to 3840×2160 |
| Video decoding | H.265(Main Profile@L5.0 High-tie)/H.264 Up to High Profile@Level5.0) |
| Audio decoding | G.711A,G711U,G726 |
| Synchronous Playback | 16CH |
| Decoding Ability | 4CH 1080P@30FPS/1CH 4K@30FPS |
| Preview | Synchronous Preview | 16 |
| Multi-screen Display | 1, 4, 8, 9, 16 views |
| Playback | Record Mode | Manual; Schedule (general; MD; alarm; intelligent) |
| AI Search | Search by target classification (human, vehicle,non-motor vehicle) |
| Backup | USB device |
| Playback Function | 1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (cut/file); partially enlarge; audio on/off |
| Network | Network Protocol | HTTP; TCP/IP; IPv4; UPnP; SNMP; RTSP;UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; P2P; Auto register |
| Mobile Phone Access | Android; iOS |
| Interoperability | ONVIF; SDK |
| Browser | IE8 or later |
| HDD | SATA | 2 |
| ESATA | 0 |
| Max Capacity | 14 TB |
| External Interface | PoE Ports | 0 |
| Network Interface | 1 RJ45 1000M |
| VGA | 1 |
| HDMI | 1 |
| CVBS | 1 |
| USB | 2 USB 2.0 (1 on front panel, 1 on back panel) |
| RCA Input | 1 |
| RCA Output | 1 |
| Alarm Input | 8 |
| Alarm Output | 4 |
| RS-232 | 0 |
| RS-485 | 1 |
| Other Function | Two-way Talk | Yes |
| Alarm Linkage | Record; Snapshot; Buzzer; Log; Preset; Email |
| Picture Capture | Support JPEG Capture |
| General Parameter | Front Panel | S |
| Packing | 405x335x120mm |
| Dimensions | 1U 360x262x48mm |
| Weight | 2.3Kg(No HDD) |
| Installation | Desktop Installation |
| Power Supply | DC 12V 3A |
| Working Temperature | -10?--+55? |
| Working Humidity | 10%--90% |
| Consumption | 7W(without HDD) |
| Certifications | Certifications | CE/FCC |
