HIKVISION (DS-7764NI-M4) 64 KANAL 12MP H265 400Mbps 4x14TB SATA 2xHDMI 2xVGA 1xSES NVR KAYIT

Aradığınız her şey tek platformda...

Giriş Yap Hesap Oluştur

info@yildizguvenlik.com.tr 0543 9641205

Arama

HIKVISION (DS-7764NI-M4) 64 KANAL 12MP H265 400Mbps 4x14TB SATA 2xHDMI 2xVGA 1xSES NVR KAYIT

Henüz Değerlendirilmemiş

Stok Kodu

: 6931847188122

Stok Miktarı

: 2 ADET

Markası

: HIKVISION

Whatsapp ile Sipariş

ALARM DESTEĞİ

Var

ANALİZ

Var

DİSK SAYISI

KANAL SAYISI

POE DESTEĞİ

YOK

SIKIŞTIRMA TEKNOLOJİSİ

H.265 / H.265+

SES DESTEĞİ

DAHİLİ MİKROFON

64-ch 1.5U 8K NVR

H.265+/H.265/H.264+/H.264 video formats
Up to 64-ch IP camera inputs
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080p decoding capacity
Up to 400 Mbps incoming bandwidth and 400 Mbps outgoing bandwidth
2 HDMI and 1 VGA interfaces, 8K or dual 4K video outputs

Video and Audio
IP Video Input :
64-ch

Up to 32 MP resolution

*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Incoming Bandwidth : 400 Mbps
Outgoing Bandwidth : 400 Mbps
HDMI 1 Output : 8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI 2 Output :
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

*: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.
VGA Output : 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode : HDMI1/VGA simultaneous output, HDMI1/HDMI2 independent output
CVBS Output : 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Audio Output : 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio : 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

Decoding
Decoding Format : H.265+/H.265/H.264+/H.264
Recording Resolution :
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF

*: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Synchronous Playback : 16-ch
Decoding Capability : 2-ch@32 MP (30 fps)/2-ch@24 MP (30fps)/4-ch@16 MP (30fps)/8-ch@8 MP (30fps)/16-ch@4 MP (30fps)/32-ch@2 MP (30fps)
Dual-Stream Recording : Support
Stream Type : Video, Video & Audio
Audio Compression : G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2

Network
Remote Connection : 128
Network Protocol : TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface : 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces

RAID
RAID Type : N/A

Auxiliary Interface
eSATA : 1 eSATA interface
SATA : 4 SATA interfaces
Capacity : Up to 14 TB capacity for each HDD
Serial Interface : 2 RS-485 (half-duplex), 1 RS-232
Alarm In/Out : 16/9
USB Interface : Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Ctrl 12V :
Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered.

*: The Ctrl 12V power is controlled by alarm output 9.
DC 12V12 VDC, 1 A power output

General
Power Supply : 100 to 240 VAC, 50 to 60 Hz
Consumption : ≤ 15 W (without HDD)
Working Temperature : -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity : 10% to 90%
Chassis : 19-inch rack-mounted 1.5U chassis
Dimension (W × D × H) : 445 × 400 × 75 mm ( 17.5"× 15.7" × 3.0")
Weight : ≤ 5 kg (without HDD, 11 lb.)

Certification
FCC : Part 15 Subpart B, ANSI C63.4-2014
CE :
EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:201

9, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
