| New 4.0 user interface |
| · P2P remote surveillance, video play on mobile device |
| · 4–ch@1080P(30FPS), self-adaptive decoding capability |
| · Support for mainstream cameras of ONVIF and RTSP protocol |
| · Smart H.265+/Smart H.264+/H.265/H.264 |
| · VGA/HDMI simultaneous video output, maximum resolution of HDMI is 1080P |
| · Remote configuration and management of IPCs, such as setting parameters, acquiring information and upgrading IPCs of the same model in batches |
| · DHCP(Dynamic Host Configuration Protocol), HTTP(Hypertext Transfer Protocol), NTP(Network Time Protocol) and DDNS(Dynamic Domain Name System) and public areas.This NVR is suitable for places such as retail stores, families, courtyards |
| |
| |
| Technical Specification |
| System |
| Main Processor : Industrial-grade embedded processor |
| Operating System : Embedded Linux |
| Operation Interface : Web/operating in local GUI |
| Video |
| Access Channel : 4 channels |
| Network Bandwidth : 80 Mbps for access, 80 Mbps for storage and 60 Mbps for forwarding. |
| Resolution : 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF |
| Decoding Capability : 1–ch@8MP(30FPS) or 1–ch@5MP(30FPS) or
2–ch@4MP(30FPS) or 2–ch@3MP(30FPS) or
4–ch@1080P(30FPS) |
| Video Output : 1 VGA/1 HDMI simultaneous video output, maximum resolution 1080P |
| Multi-screen Display : 1/4 |
| Third Party Camera Access : Onvif, RTSP |
| Compression |
| Video Smart : H.265+/H.265/Smart H.264+/H.264 |
| Audio : PCM/G711A/G711U/G726/AAC |
| Network |
| Network Protocol : HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP,DNS, P2P |
| |
| Mobile Phone Access : iDMSS(iOS), gDMSS(Android) |
| Access Standard : ONVIF(profile T/profile S/profile G),CGI,SDK |
| Browser : Chrome, IE9 or above, Firefox |
| Record Playback |
| Multi-channel Playback : Up to 4 channels playback |
| Record Mode : Priority of record mode: Manual recording > alarm recording > motion detection recording > timedrecording |
| Storage Local : HDD and network |
| Backup : USB device |
| Playback Function : 1. Play, pause, stop, fast forward, fast backward, rewind,play by frame
2. Full screen, backup (cut/file), partially enlarge, audioon/off |
| Alarm |
| General Alarm : Motion detection, privacy masking, video loss, PIR alarm,IPC alarm |
| Anomaly Alarm : Front-end device going offline, storage error, full storage,IP conflict, MAC conflict, login lock, network security anomaly |
| Alarm Linkage : Video recording, snapshot, log, preset, tour |
| External Port |
| HDD : 1 SATA 2.0 port, up to 8 TB for a single HDD. The maximum HDD capacity varies with environment temperature |
| USB : 1 front USB 2.0 port, 1 rear USB 2.0 port |
| HDMI : 1 |
| VGA : 1 |
| RCA Input : 1 |
| RCA Output : 1 |
| Alarm None |
| Network : 1 RJ–45 port (10/100 Mbps) |
| General Parameter |
| Power Supply : DC12V, 1.5A |
| Power Consumption : Total output of NVR is ≤ 10W (without HDD) |
| Net Weight : 0.81 kg (1.79 lb) |
| Gross weight : 1.38 kg (3.04 lb) |
| Product Dimensions : 260 mm×225 mm×47.6 mm (W × L × H) |
| Box Dimensions : 87 mm×331 mm×312 mm (W × L × H) |
| Operating Temperature : -10°C to 45°C (+34°F to +113°F) |
| Storage Temperature : 0°C to 40°C (+32°F to +104°F) |
| Operating Humidity : 10%~93% |
| Storage Humidity : 30%~85% |
| Operating Altitude : 3000 m (9843 ft) |
| Installation Desktop : mounting |
| Certification : CE |
