| Camera | Image Sensor | 1/2.8” CMOS |
| Max. Resolution | 4MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto(1/25s ~ 1/1000) |
| Min. Illumination | 0.01 Lux @F2.0 |
| S/N Ratio | > 56 dB |
| Illumination Distance | IR Light: 40 m, White Light: 40m |
| Illuminator Control | Auto; Manual |
| Lens | Lens Type | Fixed-Focal |
| Focal Length | 3.6mm |
| Max. Aperture | F2.0 |
| Iris Type | Auto |
| Intelligence | Human Detection | Support |
| Smart Motion Detection | Support(based on Human Detection) |
| Perimeter Protection | NA |
| Face Detection | NA |
| Object Detection | NA |
| People Counting | NA |
| Heat Map | NA |
| AI Search | NA |
| Video | Compression | H.264H; H.264M; H.264B; H.265 |
| Video Frame Rate | Main Stream: 4MP (1 fps–25/30 fps) |
| Sub Stream: D1 (1 fps–25/30 fps) |
| Stream Capability | 2 Streams |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 1792Kbps~4Mbps |
| H.265: 1792Kbps~4Mbps |
| Day/Night | Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | DWDR |
| White Balance | Yes |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 Areas, rectangular) |
| Image Rotation | 0°/180° |
| Mirror | Yes |
| Privacy Masking | 4 Areas |
| Audio | Built-in Mic | YES |
| Built-in Speaker | NA (optional) |
| Alarm | Alarm Event | Disconnection; IP Conflict; No SD Card; Capacity Warning; SD Card Error |
| Network | Network | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Network Protocol | TCP/IP;UDP;HTTP;DHCP;DDNS;FTP;UPNP |
| Interoperability | ONVIF; CGI |
| Storage | SD Card (Optional) |
| Browser | IE: IE8 and later |
| Management Software | PC Software(SVMS) |
| Mobile Client | IOS; Android |
| Port | Audio Input | NA (optional) |
| Audio Output | NA (optional) |
| Alarm Input | NA (optional) |
| Alarm Output | NA (optional) |
| Power | Power Supply | 12V DC (±30%)/PoE (802.3af) |
| Power Consumption | Max. 3W |
| Environment | Operating Conditions | –30°C to +60°C (–22°F to +140°F)/Less than 95% RH |
| Storage Conditions | –40°C to +60°C (–40°F to +140°F) |
| Protection Grade | IP67 |
| Structure | Casing | Metal( pedestal: plastic ) |
| Dimensions | 65mm×65mmx155mm |
| Net Weight | 370g |
