PFS3010-8GT-96
 10-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE
  * The parameters and datasheets below can only be applied to V2.0 (version 2.0)
 > Intelligent PoE
 > 8-pin assignment PoE power supply
 > Long distance PoE
 > PoE watchdog
 > BT 90W
 > All-giga ports
 > Wide working temperature


    |   Hardware   |
  |   Data Transmission Port   |    Port 1–8: 8 × RJ-4510/100/1000 Mbps (PoE)  Port 9-10: 2 × RJ-45 10/100/1000 Mbps (Uplink)   |
  |   Power Supply   |    48 V - 57 V DC   |
  |   Operaing Temperature   |    –10 °C to +55 °C (+14°F to +131°F)   |
  |   Operating Humidity   |    5% – 95% (RH)   |
  |   Storage Temperature   |    –20 °C to +70 °C (–4°F to +158°F)   |
  |   Storage Humidity   |    5% – 95%(RH)   |
  |   Power Consumption   |    Idling: 3 W  Full load: 96 W   |
  |   Performance   |
  |   Capacity   |    20 Gbps   |
  |   Packet Forwarding Rate   |    14.88 Mpps   |
  |   Packet Buffer Memory   |    1.5 Mbit   |
  |   MAC Table Size   |    4K   |
  |   Communication Standard   |    IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x   |
  |   PoE   |
  |   PoE Standard   |    IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt   |
  |   PoE Power   |    96 W   |
  |   Power Consumption Management   |    Yes   |
  |   PoE Pin Assignment   |    1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)   |
  |   Long Distance PoE   |    250 m long distance PoE transmission   |
  |   General   |
  |   Statics Protection   |    Air discharge: 8 kV  Contact discharge: 6 kV   |
  |   Thunder-proof   |    Common mode: 4 kV  Differential mode: 2 kV   |
  |   Net Weight   |    0.50 kg (1.10 lb)   |
  |   Gross Weight   |    1.32 kg (2.91 lb)   |
  |   Product Dimensions   |    190 mm × 100 mm × 30 mm (7.48" × 3.94" × 1.18")   |
