- Software Function
- Long Range :
Ports 1 to 16: up to 300 m.
Long range performance may vary depend on camera model or cable condition.
- Port Isolation :
Ports 1 to 16: port isolation mode to improve network security
Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.
- PoE Watchdog : Ports 1 to 16: auto detect and restart the cameras that do not respond.
- QoS :
QoS is used to allocate bandwidth to different services so as to provide end-to-end service quality assurance.
Support port-based priority configuration.
Support SP, WRR priority schedule mode.
- Loop Prevention :
Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.
Support 802.1D STP.
Suppport 802.1w RSTP.
- VLAN :
VLAN is used for network scale planning and network health improvement.
Support 802.1Q.
Configurable VLAN ID from 1-4094.
Support Trunk, Access port mode.
Support Max. 4094 VLAN.
- HPP :
Support one-click activation and remote management via Hik-Partner Pro. Functions supported:
1. Display the port rate.
2. Display the port bandwidth utilization rate.
3. Display topology information.
4. Display the alarm status.
5. Restart ports and devices.
6. Remotely upgrade the device.
- System Maintenance : Remote upgrade, default parameters recovery, logs viewing, basic network parameters configuration, import and export configuration, time sync
- Port Rate-Limiting Port rate-limiting is used for port bandwidth adjustment to prevent network congestion.
- Storm Control :
Storm control is used to prevent switch ports from being blocked by broadcast or multicast storms in the LAN, which may affect network communication.
Support port rate limiting based on broadcast, multicast, and unknown unicast packets.
