DAHUA (ARC3000H-FW2) KABLOSUZ+2G+3G+4G ALARM PANELİ

Input/Output

Wireless Zone

150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)

Port

Network Port

1 × RJ-45 10 M/100 M Ethernet port

Network Mode

Europe: GSM:900/1800 MHz, WCDMA:B1/B5/B8, LTE-FDD:B1/B3/B5/B7/B8/B20, LTE-TDD:B38/B40/B41;

USA: GSM:850/900/1800/1900 MHz, WCDMA:B1/B2/B5/B8, LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B28, LTE-TDD:B40;

Dual SIM single standby

Storage Battery

Built-in lithium battery

Indicator Light

1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)

Button

1 × reset, 1 × power, 1 × AP

Buzzer

Built-in

Function

Tamper Alarm

Yes

SMS

Yes (up to 5 phone numbers)

Calling Alarm

Yes (up to 5 phone numbers)

Video Linkage

Yes

Network Protocol

TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP

Remote Upgrade

Cloud update

Arm and Disarm

App; keyfob; schedule

Power Failure Protection for Configured Parameters

Yes

User Management

Share function for App users

Cache

Max. 50 entries (ANR)

Low Battery Alarm

Yes

Search

Search for push messages, device status, and program version, and detect signal strength

Wireless

Carrier Frequency

433.1 MHz–434.6 MHz

Communication Distance

Up to 1,200 m (3,937.01 ft) in an open space

Communication Mechanism

Two-way

Encryption Mode

AES128

Wi-Fi

2.4G

Frequency Hopping

Yes

General

Power Supply

12 V DC, 1.5 A (Europe, UK and USA power adapters are optional)

Operating Temperature

–10 °C to +50 °C (+14 °F to +122 °F) (indoor)

Operating Humidity

10%–90% (RH)

Product Dimensions

163.0 mm × 163.0 mm × 32.0 mm (6.42" × 6.42" × 1.26") (L × W × H)

Packaging Dimensions

219.0 mm × 187.0 mm × 91.0 mm (8.62" × 7.36" × 3.58") (L × W × H)

Installation

Wall mount; Desktop

Net Weight

0.38 kg (0.84 lb)

Gross Weight

0.8 kg (1.76 lb)

Certifications

CE

Casing

PC + ABS

Battery Life

Storage battery standby for 12 hours
