Facial Recognition Door station

4.3-inch colorful LCD screen with 800 × 480 resolution
2 × 2 MP wide-angle HD lens
IP65 protection level
Built-in M1 card reading module
Multiple interfaces: RJ45, RS-485, alarm input, relay, Wiegand
Convenient configuration via Web remotely
Convenient unlock methods: face, cards, PIN code

System parameters
Operation system : Linux
ROM : 1 GB
RAM : 4 GB
Processor : Embeded high performance processor

Display parameters
Screen size : 4.3-inch
Operation method : /
Type : Colorful LCD
Resolution : 800 × 480

Video parameters
Lens : 2 MP HD camera
Resolution :
Main stream: 1080p@30fps, 720p@30fps

Sub stream: VGA@25fps, VGA@30fps
FOV/
Wide dynamic range (WDR) : Digital WDR/120 dB
Supplement light : IR light, up to 3 m
Video compression standard : H.264; h.265; MJPEG

Audio parameters
Audio input : 1 built-in omnidirectional microphone
Audio compression standard : G.711 U?G.711 A?Opus?AAC-LD?AAC-LC?G.726?G.722.1
Audio output : 1 built-in loudspeaker
Audio compression bitrate : 64 Kbps
Audio quality : Noise suppression and echo cancellation
Volume adjustment : Adjustable

Capacity
User capacity : 10,000
Face capacity : 5000
Card capacity : 50,000
Fingerprint capacity : /

Network parameters
Network protocol : TCP/IP, RTSP, ipv6, onvif
Wi-Fi/
Bluetooth/
3G/4G/

Device interfaces
Alarm input : 4
Network interface : 1 RJ-45 10/100/1000 Mbps self-adaptive
TAMPER : 1
Exit button : 1
RS-485 : 2 RS-485 (Half duplex, HIKVISION)
USB : /
Wiegand : /
TF card : /
Alarm output : /
Lock control : 2 relays, Max. 30 VDC, 2 A
Door contact input : 1

General
Button : /
Installation : Flush mounting
Indicator : /
Weight :
Net weight: 0.995 kg

Gross weight: 1.592 kg
Protective level : IP65
Working temperature : -30 °C to 60 °C (-22 °F to 140 °F)
Working humidity : 10% to 90% (no-condensing)
Dimension (W × H × D) : 373 mm × 124 mm × 43.7 mm (14.69" × 4.88" × 1.72")
Battery/
Power supply : 12 VDC, 1.5 A
Application environment : Outdoor
Power consumption : ≤ 13 W
Language : English, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese (Taiwan), Latin American Spanish
