4 wire HD Kits

HD TVI video quality
7-inch LCD screen
Plug & Play
Water and dust resistant (IP65)

Door station/Video parameters
Supplement light : IR light, up to 3 m
Resolution : Stream resolution: 1280 x 720@60fps
FOV : Horizontal: 117°, Vertical: 70°, Diagonal: 141°

Door station/Audio parameters
Audio input : Built-in omnidirectional microphone (≤50 cm)
Audio output : Built-in loudspeaker (30 cm/76 dB, 50 cm/72 dB)

Door station/Device interfaces
Lock control : 1 relay, max 30 V 1 A
Debugging port : 1
Four-wire : 1 four-wire interface

Door station/General
Button : 1 physical button(s)
Power supply : 12 VDC
Power consumption : Max. 4 W
Working temperature : -30 °C to 60 °C (-22 °F to 140 °F)
Working humidity : 10% to 90%
Dimensions : 145 mm × 55 mm × 24 mm (5.71" × 2.17" × 0.94")
Application environment : Outdoor
Installation : Surface mounting
Protective level : IP65, IK08
Material : Metal

Indoor station/Display parameters
Operation method : Physical button
Type : 7-inch colorful TFT
Resolution : 1024 x 600

Indoor station/Audio parameters
Audio input : Built-in omnidirectional microphone (≤50 cm)
Audio output : Built-in loudspeaker (30 cm/76 dB, 50 cm/72 dB)

Indoor station/Capacity parameters
Linked indoor extensions capacity : 2
Linked doorphone capacity : 2
Linked analog camera : 1

Indoor station/Device interfaces
Power supply input : 12V DC
Debugging port : 1
Four-Wire interface : 4, 2 for indoor extensions, 2 for doorphones
DIP switch : 1 Bit
BNC : 1

Indoor station/General
Button : 4 physical buttons
Power supply : 12 VDC
Power consumption : ≤4 W
Working temperature : -10° C to + 55° C (14° F to 131° F)
Working humidity : 10% to 90%
Dimensions (W × H × D) : 178 mm x 132 mm x 19 mm (7.01" × 5.20" × 0.75")
Installation : Surface mounting
Application environment : Indoor
