| Camera |
| Image Sensor | Fixed Lens: 1/2.8" CMOS PT Lens: 1/2.8" CMOS |
| Pixel | Fixed Lens: 3 MP PT Lens: 3 MP |
| Max. Resolution | Fixed Lens: 2304 (H) × 1296 (V) PT Lens: 2304 (H) × 1296 (V) |
| ROM | 256 MB |
| RAM | 256 MB |
| Scanning System | Progressive |
| Min. Illumination | Fixed Lens: 0.0005 lux@F1.0 (Color, 30 IRE); 0 lux (Illuminator on) PT Lens: 0.0005 lux@F1.0(Color, 30 IRE); 0 lux (Illuminator on) |
| Illumination Distance | Fixed Lens: 30 m (98.43 ft) (Warm light) PT Lens: 50 m (164.04 ft) (Warm light) |
| Illuminator On/Off Control | Fixed Lens: Manual; Auto; Off PT Lens: Manual; Auto; Off |
| Illuminator Number | Fixed Lens: 4 (Warm light) PT Lens: 4 (Warm light) |
| Lens |
| Focal Length | Fixed Lens: 2.8 mm PT Lens: 3.6 mm; 8.4 mm |
| Max. Aperture | Fixed Lens: F1.0 PT Lens: 3.6 mm: F1.0; 8.4 mm: F1.0 |
| Field of View | Fixed Lens: H: 93.5°; V: 51.9°; D: 110.1° PT Lens: 3.6 mm: H: 81.5°; V: 44.3°; D: 96.3° 8.4 mm: H: 15.1°; V: 8.4°; D: 17.8° |
| Close Focus Distance | Fixed Lens: 1.1 m (3.61 ft) PT Lens: 3.6 mm: 1.7 m (5.58 ft); 8.4 mm: 6 m (19.69 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.8 mm | 40 m (131.23 ft) | 15.8 m (51.84 ft) | 8 m (26.25 ft) | 4 m (13.12 ft) |
| 3.6 mm | 51.43 m (168.73 ft) | 20.31 m (66.65 ft) | 10.29 m (33.75 ft) | 5.14 m (16.87 ft) |
| 8.4 mm | 120 m (393.7 ft) | 47.4 m (155.51 ft) | 24 m (78.74 ft) | 12 m (39.37 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
| PTZ | |
| Pan/Tilt Range | Fixed Lens: Pan: 0° to 210°; Tilt: -7° to +20° (manual) PT Lens: Pan: 0° to 350°; Tilt: 0° to +90° (Electric) |
| Manual Control Speed | Pan: 40°/s; Tilt: 40°/s |
| Preset Speed | Pan: 40°/s; Tilt: 40°/s |
| Preset | 50 |
| Tour | 8 (up to 32 presets per tour) |
| Power-off Memory | Yes |
| Smart Event | |
| Human Detection | Yes |
| Vehicle Detection | Yes |
| Intelligence | |
| Smart Tracking | Auto tracking lite Linkage tracking |
| SMD | SMD 3.0 |
| Active Deterrence | |
| Light Warning | White light warning |
| Sound Warning | Offers 3 sound alarm. Sound can be set from 1-100. Play times can be set from 1-10. |
| Video | |
| Video Compression | Smart H.265+ |
| Streaming Capability | 1 stream |
| Resolution | Fixed Lens: 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); 640 × 360 (640 × 360) PT Lens: 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); 640 × 360 (640 × 360) |
| Video Frame Rate | Fixed lens:Main stream: 3M/1080p/720p/640 × 360@(15 fps) PT lens:Main stream: 3M/1080p/720p/640 × 360@(15 fps) |
| Bit Rate Control | VBR |
| Video Bit Rate | H265: 54 kbps–1280 kbps |
| WDR | Fixed Lens: DWDR PT Lens: DWDR |
| White Balance | Auto |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Motion Detection | Yes |
| Image Rotation | 180° |
| S/N Ratio | ≥55 dB |
| Audio | |
| Built-in MIC | Yes |
| Built-in Speaker | Yes |
| Network | |
| Carrier Network System | 4G |
| Wireless Carrier Frequency Band | EAU/EUR: LTE-FDD: B1/B3/B5/B7/B8/B20/B28 LTE-TDD: B38/B40/B41 LA: LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66 LTE-TDD: B38/B40/B41 |
| Max. Transmission Power | 4G: Power class3: 23 dBm ± 2.7 dB |
| Storage | Micro SD card (512 GB) |
| Management Software | DMSS |
| Mobile Client | Android;iOS |
| Certification | |
| Certifications | CE: EN 55032/EN 55035/EN 50130-4/EN 61000-3/EN 62368-1/EN 301489 |
| Port | |
| Audio Input | 1 channel (built-in mic) |
| Audio Output | 1 channel (built-in speaker) |
| Alarm Linkage | warning light; audio |
| Alarm Event | Motion detection; human detection; vehicle detection |
| Power | |
| Power Supply | Power supply: Built in 65Wh lithium battery Comes with 8 W solar panel Charging: USB Type-C (Supports QC2.0) |
| Power Consumption | Super Power Saving Mode: 40 mW (4G keep-alive) AOV Mode: 170 mW (1 frame every 2 seconds, SD card recording, 4G keep-alive) Performance Mode 1: 2.4 W (4G streaming, SD card recording, PTZ static, illuminator off) Performance Mode 2: 3.7 W (4G streaming, SD card recording, PTZ static, illuminator on) Maximum Power Consumption: 8.0W (4G streaming, SD card recording, PTZ moving, illuminator on, speaker on) |
| Power Adapter | Optional |
| Battery Capacity | 65 Wh |
| Environment | |
| Operating Temperature | The unit device: Operating Temperature: –20 °C to +60 °C (–4 °F to +140 °F) Battery: Charging Temperature: –10 °C to +50 °C (+14°F to +122 °F) (The solar panel heating the battery first, and charging begins once the battery is heated to 0 °C) Discharging Temperature: –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Protection | IP66; TVS 2000 V lightning proof; surge protection; voltage transient protection |
| Structure | |
| Product Dimensions | 223.2 mm × 130.0 mm × 215.0 mm (8.79" × 5.12" × 8.46") (L × W × H) |
| Net Weight | 1.8 kg (3.97 lb) |
| Gross Weight | 2.5 kg (5.51 lb) |
| Filter | |
| Remarks | The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model. |
