| Camera | Image Sensor | 1/2.8" progressive scan CMOS |
| Min. Illumination | Color: 0.001 Lux @(F1.5, AGC ON) |
| Black: 0.0005 Lux @(F1.5, AGC ON) |
| Shutter Time | 1/25~1/100,000 s |
| Automatic Aperture | DC |
| Day& Night | ICR |
| Digital Zoom | 16x |
| Lens | Focal Length | 5.5-137.5mm,25x Optical Zoom |
| Aperture Range | F1.68-F3.67 |
| Field of View | H: 53.6-3.08°(Wide - Tele) |
| Working Distance | 100mm-1000mm (Wide - Tele) |
| Compression Standard | Video Compression | H.265 / H.264 / MJPEG |
| H.265 encoding type | Main Profile |
| H.264 encoding type | Base Line Profile / Main Profile / High Profile |
| Video Bitrate | 32 Kbps~16Mbps |
| Audio Compression | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Audio Bitrate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) |
| Image | Main Stream Resolution | 50Hz: 25fps (2560×1440,1920 × 1080, 1280 × 960, 1280 × 720);60Hz: 30fps (2560×1440,1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream 1 | 50Hz: 25fps (704 ×576); 60Hz: 30fps (704 ×576)30fps(1280×720) |
| Image Setting | Corridor mode, saturation, brightness, contrast and sharpness can be adjusted by client or browser |
| Backlight Compensation | Support |
| Exposure Mode | Automatic exposure/aperture priority/shutter priority/manual exposure |
| Focus Control | Auto focus/one-time focus/manual focus |
| Area Exposure/Focus | Support |
| Defog | Support |
| EIS | Support |
| Day &Night | Auto(ICR) / Color / B/W |
| 3D Noise Reduction | Support |
| Image overlay | Support BMP 24 bit image overlay, optional region |
| ROI | ROI supports one fixed region for each three-bit stream |
| Network Function | Network Storage | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS) |
| Protocol | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G) ,GB28181-2016,OBCP |
| PTZ | Pan Range | 360° endless |
| Pan Speed | 0.1°~120° /s |
| Tilt Range | -18°~90° |
| Tilt Speed | 0.1°~120°/s |
| Number of Preset | 255 |
| Patrol | 6 patrols, up to 18 presets per patrol |
| Pattern | 4 , with the total recording time not less than 10 mins |
| Power loss recovery | Support |
| Infrared | IR distance | Up to 120m |
| IR intensity | Automatically adjusted, depending on the zoom ratio |
| Port | Audio I/O | 1 input,1 output(optical) |
| Alarm I/O | 1 input,1 output(optical) |
| General | Power | DC12V 3A, PoE(803.at) |
| Working temperature | -40? -60? |
| Humidity | 90% or less |
| Protection level | Ip66, TVS 4000V Lightning protection, surge protection |
| Mount option | Wall Mounting, Ceiling Mounting |
| Weight | 3.5kg |
