| Thermal |
| Detector Type | Vanadium oxide uncooled focal plane detector |
| Effective Pixels | 400x300 |
| Pixel Pitch | 17 μm |
| Stectral Range | 8 μm–14 μm |
| Thermal Sensitivity (NETD) | ≤40 mK |
| Focal Length | 7.5mm, 13mm |
| Field of Mode | 7.5 mm: horizontal: 53.7°, vertical: 39.7° 13 mm: horizontal: 30°, vertical: 22.6° |
| Focus Mode | Fixel Focal |
| Aperture | F1.0 |
| Digital Detail Enhancement (DDE) | Yes |
| Thermal Image Stabilization | Electronic Image Stabilization |
| AGC | Auto; manual |
| Noise Reduction | 2D NR; 3D NR |
| Image Flip | 90°/180°/mirror |
| Color Palettes | 18 color modes selectable such as Whitehot/Blackhot/Ironrow/Icefire. |
| Temperature Measurement Range | 30°C ~+45°C |
| Temperature Accuracy | Max ±0.3°C with blackbody Max ±1°C without blackbody |
| Temperature Mode | Spot: 12 Line: 12 Area: 12 Support 12 rules simultaneously |
| Visible Lens |
| Focal Length | 4mm | 8mm |
| Max Aperture | F2.0 | F1.9 |
| Angle of View | H: 84° V: 45° | H: 40° V: 22° |
| Audio and Video |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Resolution | Main stream: (1280 × 1024/1280 × 960/1280 × 720/400 × 300), 1280 × 960 by default; Sub stream: (640 × 512/640 × 480/400 × 300@), 400 × 300 by default |
| Audio Compression | G.711a; G.711mu; AAC; PCM |
| Image Encoding Format | JPEG |
| General Function |
| Two-way Talk | Yes |
| Network Protocol | HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP |
| Region of Interest (ROI) | Yes |
| Edge Storage | FTP; Micro SD card (256G, hot plug) |
| Interoperability | ONVIF; CGI; Dahua SDK |
| Browser | IE: IE8 and the later, and explorer with IE core Google: 42 and the earlier Firefox: 42 and the earlier Safari: 10 and the earlier |
| User/Host | 20 channels at most (the total bandwidth 64M) |
| Security | Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access |
| User Management | Support 20 users at most and users are classified as two groups-administrator group and user group. |
| Malfunction Detection | Network disconnection; IP addresses conflict; SD card error (status or storage space) |
| Port |
| Analog Video Output | 1 channel of CVBS output with BNC port |
| Network | 1 10M/100M Ethernet port (RJ-45) |
| Alarm Input | 2 channels |
| Alarm Output | 2 channels |
| Audio Input | 1 channel |
| Audio Output | 1 channel |
| Alarm Linkage | SD card recording/on-off output/ siren and light/email/PTZ/snapshot |
| Alarm Event | Motion detection/privacy mask/audio detection/SD card abnormality/network abnormality/anti-burn warning |
| RS-485 | 1 channel |
| Power |
| Power Supply | 12V±20% DC, 1.2A, PoE (802.3af), ePoE |
| Power Consumption | Basic: 5.0W Maximum: 12W (power adapter excluded) |
| Enviroment |
| Operating Temperature | 10°C to +30°C |
| Operating Humidity | ≤95% |
| Self-Adaptive | Auto heating to protect the chip under the cold environment |
| Physical Characteristics |
| Protection Grade | IP67, anti-surge 6KV, anti-elctrostatic 8KV (touched by objects), anti-elctrostatic 15KV (air) |
| Packaging Dimensions | 365 mm × 175 mm × 176 mm (14.37" × 6.89" × 6.93") |
| Net Weight | ≤1.4 kg (3.09 lb) |
| Gross Weight | ≤1.9 kg (4.19 lb) |
| Power Adaptor | Selectable |
| Lens | Contained |
| Certification |
| Certifications | CE; FCC |
