| Image Sensor | | 1280×800 (megapixel) CMOS |
| Illumination | | Red LED/ White LED |
| Symbologies | 1D | EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey, etc. |
| 2D | PDF417, QR Code, Data Matrix, Aztec, Maxicode, etc. |
| Postal | USPS Postnet, Royal Mail, KIX Post, Australian Postal, etc. |
| Resolution | | ≥3mil |
| Typical Depth of Field | EAN-13 | 45mm-510mm (13mil) |
| Code 39 | 75mm-220mm (5mil) |
| PDF 417 | 70mm-215mm (6.7mil) |
| Data Matrix | 50mm-220mm (10mil) |
| QR Code | 20mm-330mm (15mil) |
| Scan Angle | | Pitch: ±55°, Skew: ±55°, Roll: 360° |
| Min. Symbol Contrast | | 25% |
| Field of View | | Horizontal 39°, Vertical 24° |
| Aiming | | Green LED |
| Physical | Dimensions (L×W×H) | 113.5(W)×73.3(D)×159.0(H)mm |
| Weight | 162g |
| Notification | Beep, LED |
| Operating Voltage | 5VDC±5% |
| Current@5VDC | Operating : 238.2mA (typical), 260.5mA (max.) |
| Idle : 71.3mA |
| Interfaces | RS-232, USB |
| Rated Power Consumption | 1289.6mW (typical) |
| Environmental | Operating Temperature | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5%~95% (non-condensing) |
| ESD | ±15 KV (air discharge); ±8 KV (contact discharge) |
| Drop | 1.5m |
| Sealing | IP42 |
| Certifications | Certificates & Protection FCC | Part15 Class B, CE EMC Class B, RoHS |
